2S10A Lithium Ion Battery Management System

1 Voltage
Charging voltage DC:   8.4V CC/CV
Balance voltage for single cell
2 Current
Balance current for single cell
Current consumption Max:   20µA
Maximal continuous charging current    10A
Maximal continuous Discharging current    10A
3 Over charge Protection
Over charge detection voltage for single cell    4.25V ± 0.025V
Over charge detection delay time    0.5 - 1.8S
Over charge release voltage for single cell    4.05 ± 0.05V
4 Over discharge protection
Over discharge detection voltage for single cell    2.50V ± 0.08V
Over discharge detection delay time    50 - 170ms
Over discharge release voltage for single cell    3.0 ± 0.1V
5 Over current protection
Over current detection voltage    100 ± 30mv
Over current detection current    19 ± 3A
Detection delay time    5 - 15ms
Release condition cut load
6 Short protection
Detection condition Exterior short circuit
Detection delay time    200-500us
Release condition cut load
7 Resistance Protection circuitry(MOSFET)   ≤ 60mΩ
8 Temperature
Operating Temperature Range   -20 ~ +60°C
Storage Temperature Range    -20 ~ +65°C
9 Dimension  L48*W9*T2.5mm
